NovArk Power 3000kVA Heavy-Duty Diesel Generator Set
Detail Information
Product Introduction
Engineered for maximum reliability, the NovArk Power 3000kVA generator set is a premium heavy-duty power generation solution designed for critical backup power and continuous prime power applications. This robust machine is ideal for a wide range of demanding scenarios, including industrial factories, large-scale shopping malls, hospitals, mission-critical data centers, outdoor construction projects, and emergency rescue operations.
Why Choose the Nov-3000YC?
Premium Core Configuration: Powered by a reliable Yuchai engine and paired with a pure copper brushless alternator, this unit guarantees stable voltage output and exceptional electrical performance.
Robust & Durable Construction: The heavy-duty steel frame is reinforced with thickened materials to withstand severe impacts. The surface is treated with professional anti-corrosion and anti-rust coating, ensuring long-lasting durability even in harsh outdoor environments.
Smart Control System: Equipped with an advanced digital monitoring panel, the intelligent control system allows for effortless operation. It fully supports automatic start/stop functions and provides real-time fault alarms for ultimate peace of mind.
Eco-Friendly & Cost-Efficient: Designed with low fuel consumption and advanced noise-reduction technology, this generator delivers high power output while minimizing operational costs and environmental impact.
Flexible & Mobile Design: The modular design allows for quick installation and space-saving storage. For mobile applications, it features heavy-duty rotating casters and secure brakes, ensuring safe and highly efficient relocation across job sites.
Product Specifications
Runtime Environment | ambient temperature（℃） | /-10～40/ |
ambient temperature | ≤60% | |
comply with standards | Meets ISO3046 and ISO8528 requirements | |
Ventilation Requirements | Adequate ventilation is mandatory; ensure intake and exhaust vents are clear at all times. | |
Operating water temperature（℃） | 75-95 | |
continuous working load | ≤90% | |
continuous running time（h） | 8-12 | |
Packaging Size | 6795*2780*3060mm | |
packaging | Bulk / Flat-packed for easy container loading | |
Available Options | Open Frame Type, Mobile Trailer Type, Silent Canopy Type | |
Applicable scenarios | Industrial Prime Power, Commercial Backup, Construction Sites, Medical Facilities, Outdoor Operations | |
diesel generator set | model | Nov-3000YC |
rated power; normal power（kVA） | 3000 | |
standby power（kVA） | 3300 | |
Rated voltage（V） | 230/400 | |
rated current（A） | 4320 | |
rated frequency（Hz） | 50/60 | |
power factor | 0.8 | |
dimension（mm） | 6795*2780*3060 | |
weight（kg） | 16850 |
diesel engine | brand | Guangxi Yuchai Machinery Co., Ltd. (T3) |
model | YC6C1520-D31 | |
number of cylinders | 16 | |
type | V | |
intake method | Turbocharged Intercooled | |
Bore × Stroke（mm） | 200*210 | |
oil capacity（L) | 520 | |
motor oil grade | CF level or above | |
oil consumption rate（g/kw·h） | ≤1.0 | |
fuel consumption rate（g/kw·h） | ≤195 | |
rated speed（r/min） | 1500 | |
technical route | Electronically Controlled Unit Injector | |
Startup method | Electronically Controlled Unit Injector |
generator | brand | Kwise |
model | KAL404G4 Parallel Operation | |
Excitation method | AVR automatic voltage regulation | |
voltage regulation method | brushless self-excited | |
Rated voltage(v) | 400/230 | |
number of phases; phase number | three-phase four-wire system | |
temperature rise（℃） | 125 | |
Protection Class/Insulation Class | IP21 / Class H | |
no-load voltage adjustment range | ≥±5% |
Note:
Global Voltage & Frequency Options:
Asia, Africa, Europe: 50Hz, 230V/400V, 3-Phase
Americas, Japan, South Korea: 60Hz, 230V/440V, 3-Phase
Customization: Voltage and frequency can be customized to meet specific regional grid requirements.
